| Feature | Technical data | Additional information |
| Housing | zinc die-cast | |
| Gear ratio | 0.2 … 244 | |
| Speed | ≤500 min-1 | depending on transmission |
| Shaft load rating | ≤400 N | radial |
| ≤150 N | axial | |
| Potentiometer service life | 1 x 106 rotation(s) | |
| Shaft | rustproof stainless steel |
| Transducer, power output | ||
| Feature | Technical data | Additional information |
| Operating voltage | 24 V DC ±20 % | |
| Output current | 4 … 20 mA at load 500 Ω | |
| Transducer, voltage output | ||
| Feature | Technical data | Additional information |
| Operating voltage | 24 V DC ±20 % | |
| Output voltage | 0 … 10 V | |
| Measuring range | 340° ±5° (mechanical full-length) | potentiometer type 01 |
| 3600° +10° | potentiometer types 02, 03/0.1 |
| Ambient temperature | -20 … 80 °C | without oil fill |
| -10 … 80 °C | with oil fill | |
| Relative humidity | condensation inadmissible | |
| EMC | EN 61000-6-2 | interference resistance / immission |
| EN 61000-6-4 | emitted interference / emission | |
| Protection category | IP52, IP65, IP68 | EN 60529 |
